TMS320F28027PTT

microcontroller, 48LQFP, 60MHz, 32-Bit, 1.71 V ~ 1.995 V, TMS320F28027PTT, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $4.00~5.00

PartNumber:: TMS320F28027PTT

Brand:: Texas Instruments - TI | Pack: LQFP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sally's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-21

From Other Seller

Part Number:TMS320F28027PTT
US $4.00 - 5.00
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TMS320F28027PTT is a microcontroller. It provides the power of the C28x core coupled with highly integrated control peripherals in low pin-count devices. THe TMS320F28027PTT is code-compatible with previous C28x-based code, as well as providing a high level of analog integration.

Parametrics

TMS320F28027PTT absolute maximum rating: (1)Supply voltage range, VDDIO (I/O and Flash):–0.3 V to 4.6 V; (2)Supply voltage range, VDD with respect to VSS: –0.3 V to 2.5 V; (3)Analog voltage range, VDDA with respect to VSSA: –0.3 V to 4.6 V; (4)Input voltage range, VIN (3.3 V): –0.3 V to 4.6 V; (5)Output voltage range, VO: –0.3 V to 4.6 V; (6)Input clamp current, IIK (VIN < 0 or VIN > VDDIO): ±20 mA; (7)Output clamp current, IOK (VO < 0 or VO > VDDIO): ±20 mA; (8)Junction temperature range, TJ: –40 to 150℃; (9)Storage temperature range, Tstg: –65 to 150℃.

Features

TMS320F28027PTT features: (1)High-Efficiency 32-Bit CPU; (2)60-MHz, 50-MHz, and 40-MHz Devices; (3)Single 3.3-V Supply; (4)Integrated Power-on and Brown-out Resets; (5)Two Internal Zero-pin Oscillators; (6)Up to 22 Multiplexed GPIO Pins; (7)Three 32-Bit CPU Timers; (8)On-Chip Flash, SARAM, OTP Memory; (9)Serial Port Peripherals (SCI/SPI/I2C); (10)Enhanced Control Peripherals; (11)Up to 22 Individually Programmable, Multiplexed GPIO Pins With Input Filtering; (12)Peripheral Interrupt Expansion (PIE) Block That Supports All Peripheral Interrupts; (13)Three 32-Bit CPU Timers; (14)Independent 16-Bit Timer in Each ePWM Module.
