BQ24020DRCRG4

10-SON, li-ion and li-pol charger ic, 500 mA, –0.3 to 7.0 V, BQ24020DRCRG4

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.55~0.56 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.55~0.56

PartNumber:: BQ24020DRCRG4

Brand:: Texas Instruments - TI | Pack: SON | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sally's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-10

From Other Seller

Part Number:BQ24020DRCRG4
US $0.55 - 0.56
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BQ24020DRCRG4 is a single-chip, li-ion and li-pol charger ic with autonomous usb-port and ac-adapter supply management. In a single monolithic device, the BQ24020DRCRG4 offers integrated USB-port and ac-adapter supply management with autonomous power-source selection, power-FET and current-sensor interfaces, high-accuracy current and voltage regulation, charge Single-Cell Li-Ion or Li-pol Packs in Space status, and charge termination. The applications of the BQ24020DRCRG4 include: PDAs, MP3 Players, Digital Cameras, Internet appliances, Smartphones.

Parametrics

BQ24020DRCRG4 absolute maximum ratings: (1)Input voltage: –0.3 to 7.0 V; (2)Output sink/source current: 15 mA; (3)Output current: 200 mA; (4)Output current: 1.5 A; (5)Operating free-air temperature range, TA: –40 to 125 ℃; (6)Junction temperature range, TJ –40 to 125 ℃; (7)Storage temperature, Tstg: –65 to 150 ℃; (8)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 300 ℃.

Features

BQ24020DRCRG4 features: (1)Charges and powers Systems from Either AC Adapter or USB With Autonomous power-Source Selection; (2)Integrated USB Control With Selectable 100 mA and 500 mA Charge Rates; (3)Ideal for Low-Dropout Charger Designs for Single-Cell Li-Ion or Li-pol Packs in Space Limited portable applications; (4)Integrated power FET and Current Sensor for Up to 1-A Charge applications From AC Adapter; (5)Precharge Conditioning With Safety Timer; (6)power Good (AC Adapter Present) Status Output; (7)Optional Battery Temperature Monitoring Before and During Charge; (8)Automatic Sleep Mode for Low-power Consumption.
